ZKTeco SpeedFace-V5L in Dubai
Endless Data is an official ZKTeco distributor based in Dubai, UAE, supplying the ZKTeco SpeedFace-V5L Series across the UAE, MENA and selected East African markets, including Kenya and Uganda. The series includes SpeedFace-V5L, SpeedFace-V5L-RFID and SpeedFace-V5L[QR] for access control and time attendance. It combines visible-light facial authentication, optional palm authentication, card/password verification, SIP video intercom, ONVIF and flexible ZKTeco software integration. Contact Endless Data for model selection, quotation and availability.
Linux-based hybrid-biometric access control and time attendance series with visible-light facial authentication and multiple verification options.
Supports up to 10,000 users, 10,000 faces, 10,000 cards, optional 3,000 palms and 200,000 transactions; the standard SpeedFace-V5L also supports 10,000 fingerprints.
Available as SpeedFace-V5L, SpeedFace-V5L-RFID and SpeedFace-V5L[QR], with SIP video intercom, ONVIF, TCP/IP, Wiegand, RS485 and ZKTeco software integration.
Specifications
| Series Models | SpeedFace-V5L / SpeedFace-V5L-RFID / SpeedFace-V5L[QR] |
| Display | 5-inch ISP Color LCD Screen (720 × 1280) |
| Camera | 2MP WDR Binocular Camera |
| Operating System | Linux |
| CPU | Quad Core A55 @ 1.2GHz |
| Memory | 512MB RAM; 1GB RAM with optional palm; 8GB ROM |
| Fingerprint Sensor | Z-ID on SpeedFace-V5L |
| Authentication Methods | Face / Card / Password on all models; fingerprint on SpeedFace-V5L; palm optional; dynamic QR supported with model-dependent configuration |
| Fingerprint Capacity | 10,000 on SpeedFace-V5L |
| Face Capacity | 10,000 |
| Palm Capacity | 3,000 optional, requires 1GB RAM mainboard |
| Card Capacity | 10,000 |
| User Capacity | 10,000 |
| Transaction Capacity | 200,000 |
| Authentication Speed | Less than 0.35 sec face; less than 0.5 sec fingerprint; less than 0.35 sec palm |
| Authentication Distance | Face 30-170 cm; palm 15-40 cm |
| Biometric Algorithms | ZKFace V3.6; ZKFingerprint V13.0 standard / V10.0 optional; ZKPalmVein V20.1 |
| Card Options | 125 kHz ID, 13.56 MHz IC and optional multi-tech modules depending on model |
| QR Code | Dynamic QR through ZKBio CVAccess mobile app; standard QR module on SpeedFace-V5L[QR] |
| Communication | TCP/IP; optional dual-band Wi-Fi 2.4/5GHz; Wiegand input/output; RS485 |
| Access Control Interfaces | Aux Input, Aux Output, Electric Lock, Door Sensor, Exit Button, Alarm |
| Standard Functions | ADMS, DST, Photo Capture, Event Photo Capture, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Tamper Alarm, Multiple Verification Methods, AC Push / TA Push, HTTPS / SSH, Mask Detection |
| Optional Functions | SIP 2.0 Video Door Phone, ONVIF, Wi-Fi, Webserver |
| Video Intercom | ZKTeco private protocol and standard SIP protocol on ZAM230 platform |
| Supported Software | ZKBio CVAccess (AC PUSH), ZKBio Time (TA PUSH), ZKBio Zlink cloud |
| Mobile Apps | ZKBio Zlink, ZKBio Zexus |
| Power Supply | DC 12V 3A |
| Operating Temperature | -10°C to 45°C |
| Operating Humidity | 10% to 90% RH, non-condensing |
| Dimensions | 202.93 × 91.93 × 21.5 mm |
| Net Weight | 0.6 kg |
| Installation | Wall-mount; Asian Gang-box / Single Gang-box compatible |
| Certifications | ISO14001, ISO9001, CE, FCC |
Key Features
Applications & Use Cases
Dubai & UAE Biometric Access Control
Businesses in Dubai and across the UAE can use the ZKTeco SpeedFace-V5L Series for facial, card, password and model-dependent fingerprint, palm or QR authentication in access control and time attendance projects.
MENA Projects Supplied from Dubai
System integrators and businesses across MENA can source SpeedFace-V5L Series models through Endless Data in Dubai for quotations, model selection, availability and software compatibility guidance.
Kenya Buyers Sourcing from Dubai
Customers and system integrators in Kenya can source the SpeedFace-V5L Series from Endless Data in Dubai for biometric access control and attendance projects, subject to availability and delivery arrangements.
Uganda Buyers Sourcing from Dubai
Customers and system integrators in Uganda can source SpeedFace-V5L Series models through Endless Data in Dubai for offices, commercial facilities and secure-entry projects, subject to availability and delivery arrangements.
QR, RFID & Hybrid-Biometric Projects
Choose SpeedFace-V5L for fingerprint-based projects, SpeedFace-V5L-RFID where standard ID card verification is required, or SpeedFace-V5L[QR] for a dedicated dynamic QR module with ZKBio CVAccess mobile app support.
Video Intercom & Integrated Security
On the ZAM230 platform, SpeedFace-V5L supports SIP video intercom and ONVIF together with electric lock, door sensor, exit button, alarm, Wiegand and RS485 integration.
