ZKTeco SC800 in Dubai
The SC800 is a Linux-based RFID access control terminal designed for durable outdoor performance with IP65 waterproof and IK04 vandal-resistant construction. It supports multi-frequency RFID, AES256 data security, and a hidden touch keypad for enhanced touchless access. With TCP/IP, RS485, Wiegand, OSDP, and optional Wi-Fi, it integrates seamlessly with ZKBioAccess IVS for enterprise-grade security. Supplied by ZKTeco Dubai, it delivers advanced access control solutions to customers across the UAE, the Middle East, Africa, and global markets.
Fast and secure access with multi-frequency RFID and hidden touch keypad
Durable IP65 & IK04 design for outdoor applications
Specifications
| Card Capacity | 100,000 |
| Record Capacity | 200,000 |
| Display | 2.4-inch TFT LCD Color Screen |
| Operating System | Linux |
| Communication | TCP/IP, Wiegand In/Out, RS485, OSDP (Ver2.1.7), RS232 (Printer only), Wi-Fi (Optional) |
| Standard Functions | ID Card, Web Server, Automatic Status Switch, Self-Service Query, DST, 9-Digit User ID, Scheduled Bell, Anti-passback, HTTPS, AC Push to TA Push |
| Optional Functions | Multi-tech Card Module, Wi-Fi, Printer |
| Access Control Interface | 3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell |
| Auxiliary Interface | 1 AUX Input |
| Keypad | Hidden Touch Keypad |
| Indication Light | Breathing Light (White), Status Light (Red/Green) |
| Power Supply | DC 12V 3A |
| Verification Speed | Fast Multi-Frequency RFID Matching |
| Operating Temperature | -10°C to 55°C (14°F to 131°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Operating Humidity | 10%–90% RH |
| Dimensions | 143 × 85 × 19.8 mm (Length × Width × Depth) |
| Net Weight | 0.70 kg |
| Data Protection | AES256 Encryption |
| Supported Software | ZKBio Access IVS |
Applications & Use Cases
Corporate Offices & Enterprises
ZKTeco SC800 provides secure employee access and attendance using multi-frequency RFID, hidden touch keypad, and fast verification for reliable workforce management.
Industrial & Outdoor Facilities
ZKTeco SC800 features IP65 waterproof and IK04 vandal-proof design, ideal for factories, warehouses, and outdoor gates, ensuring durable and secure access control.
Educational Institutions
ZKTeco SC800 enables accurate student and staff attendance tracking, multi-card type support, and centralized reporting for efficient campus management.
Residential & Smart Buildings
ZKTeco SC800 integrates with electric locks, door sensors, exit buttons, and alarm systems, providing seamless access control and smart building automation.
